Used Automobile Radiators Production Line
Used Radiator Production line machines for the production of core Automobile Radiators.All the machines are in good technical condition and ready for production.
The line includes:
F1.Radiator TUBULAR FIN Machine for FLAT system.3-6 Rows
The Machine is designed to enable the operator to quickly change the width of fin to be produced, fin length is controlled electronically and can be changed from one size to another in a matter of seconds.
F3.Radiator TUBULAR ASSEMBLY Machine for FLAT system 1200*1200mm
The Fin Assembly Table is a quick ad easy method of assembling fin and tube into a complete radiator core. It comprises an aluminium surface top ad bottom, accurately machined to a close flatness tolerance.
F4.Radiator TUBULAR ASSEMBLY Machine for FLAT system 1000*1000 mm
The Fin Assembly Table is a quick ad easy method of assembling fin and tube into a complete radiator core. It comprises an aluminium surface top ad bottom, accurately machined to a close flatness tolerance.
F5.Radiator TUBULAR ASSEMBLY Machine for FLAT system 600*600 mm
The Fin Assembly Table is a quick ad easy method of assembling fin and tube into a complete radiator core. It comprises an aluminium surface top ad bottom, accurately machined to a close flatness tolerance.
F6.Radiator AIRWAY FIN Machine for Corrugate system.2-4 Rows
The Machine is based on a modular construction comprising - coil holder, strip tension, rolling head, At hering and pitching units, quillotine (operated pneumatically), conveyer, etc.
F7.Radiator CORE ASSEMBLY Machine for Corrugate system 1000*1000 mm
The radiator Core Assembly machine is a versatile machine designed for rapid assembly of tubes, fins and header plates into a complete radiator core ready for the banking process.
F8.Radiator CORE ASSEMBLY Machine for Corrugate system 600*600 mm
The radiator Core Assembly machine is a versatile machine designed for rapid assembly of tubes, fins and header plates into a complete radiator core ready for the banking process.
F9.Radiator TUBE FORMING Machine
The Tube Forming Machine has been specifically designed to produce a Lock seam Radiator Tube externally solder coated and cut to the desired length.The tube itself is formed from a continuous length of un tinned brass strip fed into the machine via a series of shaped rollers.From here the pre-formed tube passes through a cleansing and soldering bath where the external surfaces are
soldered together to produce a watertight tube of superior strength.
F10.CORE BAKE Oven
The gas Core Bake Oven is designed with high power ,essential for larger cores or when low residue fluxes are to be used requiring fast baking times. Temperature is automatically controlled, with a separate timer for length of baking time required. This are all situated on the main oven control panel.
F16.Press format tooling machine for Flat system 3-6 Rows
The Press Tool is a typical example of a header plate piercing tool, supplied on a quality die set with hardened pins and bushes. The working components are manufactured in high quality tool steel, hardened and ground.
- Press format tooling machine for Corrugate system 2-4 Rows
The Press Tool is a typical example of a header plate piercing tool, supplied on a quality die set with hardened pins and bushes. The working components are manufactured in high quality tool steel, hardened and ground.
F18.Press Header Plate format tooling machine with tools for Plastic tanks
The Press format tooling machine is for forming any size plastic radiator header plate
