FDM (Fused deposition modeling)

ARBURG Freeformer 2K – 3A

Manufacturer : ARBURG

The industrial additive manufacture of functional parts is highly demanding: It involves a wide range of original materials, material and colour combinations, as well as high part quality and strength. Individual settings options are required during the manufacturing process.

That’s why we developed the APF (ARBURG Plastic Freeforming) process and the freeformer specifically as an open system. Tiny plastic droplets provide the basis for flexible adjustment options. The droplet size and process control can be influenced in a targeted manner. This gives you the freedom to individually optimise the properties of your additively manufactured parts and to process your own materials

Reference : M191202

No responsibility whatsoever is assumed with respect to technical description, quality, dimensions, year of manufacturing and completeness of machines.

The descriptions are made under full reserve of potential errors which will be without any influence on a concluded sale

rea-securite
Validated & certified by Multistation
Do you need more information ?
Call me back
Request a quote

Highlights

  • Customised: different sizes with two or three discharge units
  • Unique: using qualified standard granulates to produce fully functional parts – as a complex, resilient hard/soft combination
  • High-quality: pulsed nozzle closure with piezo technology ensures high quality parts
  • Extensive: growing material database with process settings for various amorphous and semi-crystalline thermoplastics
  • Open: free programming of process – from geometrical slicing to the discharge and positioning of the droplets
  • Adaptable: modified original materials can be used quickly and easily, for example for the aerospace industry or in medical technology

Materials :
ABS, PC, PA 12 (amorph), TPU, …..

Type/Model : 2K – 3A

YOM : 2016

Building volume : 189x134x230mm

Process : FDM (Fused deposition modeling)

Condition : Good condition

Manufacturer

ARBURG
