DMG DMU 80T WITH HEIDENHAIN 426

Manufacturer : DMG MORI

DMG-DECKEL MAHO DMU 80T

5 axis machining centre

Reference : M180507-B
Location : Europe

No responsibility whatsoever is assumed with respect to technical description, quality, dimensions, year of manufacturing and completeness of machines.

The descriptions are made under full reserve of potential errors which will be without any influence on a concluded sale

rea-securite
Validated & certified by Multistation
Do you need more information ?
Call me back
Request a quote
New in 2001
CNC Heidenhain 426
Table Dimension 1.250 x 700 mm.
Travels (X/Y/Z) 880/630/630 mm.
C Axis in Table CONTINUOUS
B Axis Turning Head -91º / +12º CONTINUOUS
Rapid Traverse 30.000 mm/min
Max. Working Feed 30.000 mm/min.
Taper SK-40 DIN 69871
Turning Speeds 20-12000 rpm
Main Motor Power 19 Kw.
ATC INCLUDED
Tools at ATC   32
Max. Weight Allowed on Table   800 Kg.
Internal Coolant 40 Bar INCLUDED
HEIDENHAIN Optical Rules INCLUDED
Chip Conveyor INCLUDED
Portable Handwheel HEIDENHAIN HR-410
3D quickSET* INCLUDED
Hours On 42.771
Spindle On 19.127
Net Weight 9.500 Kg.
Tools and Accessories INCLUDED

Type/Model : DMG DMU 80T WITH HEIDENHAIN 426

YOM : 2001

Process : Other Machines Tools

Condition : Good condition

Manufacturer

DMG MORI
