Working dimensions: 2.74 mx 1.76 m
CUTTING GANTRY
Servo motor control
Cutting speed: 152.4 cm / s
7-inch LCD touchscreen, full color control panel
Safety features: Two stop discs; Four remote emergency stops
TOOL HEAD – STANDARD
Three tool mounts
Round blades 28mm / round 45mm / cutter (drag)
Pen lift assembly
Tool changing station
Tool depth gauge and depth limiters
CONVEYOR
Precision ground linear rail / rack and pinion drive system
One internal 10 Hp high flow blower and silencer with VFD control. Equipped with 380V/3ph blower
Polyurethane cutting belt (85dm) – NEW BELT TO BE INSTALLED AT NEW CUSTOMER LOCATION
DIAGNOSTIC CONTROL CABINET & SOFTWARE
Waterproof for protection of foreign particles and dust
Multi-axis motion control industrial computer /Windows 10, 64-bit operating system
cutPRO – Cutting system control and operation software
Equipped with 230V, 3 Phase, 50/60HZ with 380V step-down transformer
