KLM GmbH – Silicone dosing machine S 200 HP

Manufacturer : KLM GmbH

The silicone mixing and dosing machine S 200 HP offers a very effcient, quick and economical way to make silicone moulds and parts.
Benefts:
• economy of time, pre-work like weighing, mixing and evacuation of material is saved;
• rigid-coupled pistol dosing system for volumetrically exact mixing ratio of both components;
• direct feeding from original barrels;
• dynamic mixer for intensive and bubble-free homogenous mixing of both components;
• amount of material to be fed can be regulated / controlled;
• mixing head fxed to 1,2 m long adjustable arm for easier flling of the mould;
• base plate and machine body powder-coated;
• high-viscosity silicone and silicones with fller material can be used as well with this machine.

Reference : M191016

No responsibility whatsoever is assumed with respect to technical description, quality, dimensions, year of manufacturing and completeness of machines.

The descriptions are made under full reserve of potential errors which will be without any influence on a concluded sale

rea-securite
Validated & certified by Multistation
Do you need more information ?
Call me back
Request a quote

Technical Data:

Dimensions: W x H x D (in mm) 1200 x 1750 x 900
flow rate: (in l per minute) 8 – 10
pressure: (in bar) 8
mixing ratio (fx adjusted): 100 : 10 (or as required)
Power supply: (in V/Hz) 400 / 50



Materials :
Silicone

Type/Model : Silicone dosing machine S 200 HP

YOM : 2014

Process : Other

Number of hours : 500

Condition : Good condition

Last maintenance date : 05/06/2018

Last use date : 09/07/2018

Manufacturer

KLM GmbH
