|X (Table)||5 700 mm||0 …. 22 000 mm/min|
|Y (Carriage)||3 400 mm||0 …. 30 000 mm/min|
|Z (Spindle)||1 250 mm||0 ….. 25 000 mm/min|
The accuracy is determined by the entire finishing process.
Finishes complete the piece, clamp once and is the most effective way
for high accuracy.
Drilling, milling and grinding are fully integrated.
Fully integrated fork heads two axes to use as simultaneous 5-axis
machine. With the use of an automatic tool changer (ATC), a higher
level of automation of the system can be achieved. The automatic tool change may take place in the vertical main axis and in the vertical or horizontal machining heads. The number of tool stations store is variable. The tools are changed out of the work area, thus enabling the full working area is still usable, and collisions are avoided. The widest variable machine options and additional equipment offer a variety of treatment options for the most different workpieces.
A power interface with the control center automatically support plug
coupling for all equipment functions and technical procedures
(internal and external cooling). The direction of the heads of all
drilling and milling is automatically configured
