Polyjet

OBJET – OBJET EDEN 260VS

Manufacturer : OBJET
Reference : M191008

No responsibility whatsoever is assumed with respect to technical description, quality, dimensions, year of manufacturing and completeness of machines.

The descriptions are made under full reserve of potential errors which will be without any influence on a concluded sale

rea-securite
Validated & certified by Multistation
Do you need more information ?
Call me back
Request a quote

The Objet Eden260VS offers outstanding productivity
in a size that fits your creative environment. Express
your product vision with models up to 255 x 252
x 200 mm (10.0 x 9.9 x 7.9 in.) with ultra-fine layer
thickness, smooth surfaces and thin walls.

The Objet Eden260VS features 15 distinct 3D
printing materials — including rigid and flexible.
The Vero™ family of materials offers multiple color
options including white, gray, blue and black,
while the Tango™ family is ideal for a wide range
of applications requiring flexible or soft-touch
components. With Simulated Polypropylene and
transparent materials, the Objet Eden260VS
creates tough, durable prototypes with living hinges
and snap-fit parts, and clear models with great
dimensional stability.

3D PRINTER SPECIFICATIONS

System Size and Weight 87 x 120 x 73.5 cm (34.2 x 47.2 x 29 in.); 254 kg (559 lbs.)
Resolution X-axis: 600 dpi; Y-axis: 600 dpi; Z-axis: 1600 dpi
Accuracy 20-85 microns for features below 50 mm; up to 200 microns for full model size
Minimum Layer Thickness Horizontal build layers as fine as 16 microns (.0006 in.)
Build Modes High speed: 30-micron (.001 in.) resolution
High quality: 16-micron (.0006 in.) resolution
Software Objet Studio™ intuitive 3D printing software
Workstation Compatibility Windows 7/ Windows 8
Network Connectivity LAN – TCP/IP
Operating Conditions Temperature 18-25°C (64-77°F); relative humidity 30-70% (non-condensing)
Power Requirements 100-200 VAC, 50/60Hz, 14A; 200-240 VAC, 50-60Hz, 7A
Regulatory Compliance CE, FCC/RoHS

Type/Model : OBJET EDEN 260VS

YOM : 2015

Building volume : 255 x 252 x 200 mm (10.0 x 9.9 x 7.9 in.)

Process : Polyjet

Number of hours : 500

Condition : Very good condition
