SHINING 3D – EinScan SE

Manufacturer : SHINING 3D
Sectors : Fablabs, Education, Industry, Automotive, Medical, Aerospace, Luxury

The EinScan SE is a powerful entry-level desktop scanner, with auto-calibration and one-click scanning. It has 2 scanning modes: Automated scanning for turntable or individual scanning for larger objects.

Reference : SHINING3DeinscanSE
technique
Support
rea-paiement
Secure Payment
Do you need more information ?

EINSCAN SE 3D SCANNER

EinScan SE is a desktop 3D scanner capable of performing an individual scan in less than 8s. For this he uses structured light technology to project a series of light patterns onto the object, which deform to show its shape. Its easy-to-use software enables automatic calibration and one-click scanning. The built-in turntable is pre-calibrated and allows for full 360 degree scans in less than 2 minutes.

SIMPLE, USER-FRIENDLY OPERATION AND FAST SCANNING

  • One-click scanning
  • Automatic calibration without strict definition
  • 8 seconds for a single scan
  • 2 minutes for a 360 degree scan in auto scan mode

FINE DETAILS

Structured light scanning technology to capture the most intricate details.

COMPATIBLE WITH 3D PRINTERS

Automatic meshing for watertight 3D data Seamless connection to 3D printers API access service for 3D printers of all brands.

EINSCAN SE 3D SCANNER

3D scanner

  • Weight : 2,5 kg
  • Weight (including the box) : 4,9 kg
  • Dimensions : 570 x 210 x 210 mm
  • Texures : yes

3D Scan

  • Maximum precision : 100 microns (0.1 mm)
  • Minimum dimensions : 30 x 30 x 30 mm
  • Fixed scan maximum dimensions : 700 x 700 x 700 mm
  • Auto scan maximum dimensions : 200 x 200 x 200 mm
  • Source : structured light
  • Camera definition :1.3 Mega Pixels

Software

    • Einscan
    • File types export : .stl .obj .asc .ply
    • Compatible with Windows

Electric

  • Consumption : 50 W
  • Voltage : 12 v, 3.33A

Manufacturer

Logo Shining 3D

SHINING 3D

SHINING 3D develops, manufactures and commercializes a wide range of 3D technologies, including 3D scanners for multiple industries and applications, different types of 3D printers as well as 3D printing materials. SHINING 3D also offers through partnerships with Siemens and 3D Systems professional software from CAD design to 3D inspection and even a 3D cloud network…
